系统System:

二分频无源音箱

额定功率Power handling:

300W

Low (8 ohm):

1x 10in,250W,8   ohm

High (8 ohm):

1x 1.75in,50W,8   ohm,1in exit

频率响应Frequency response:

60Hz~19kHz (±3dB)

灵敏度Sensitivity-1w/ 1m:

94 dB

声压级Max. SPL peak:

119 dB

角度Dispersions:

90°x 60°(HxV)

分频点Crossover point:

1.8kHz

插座Input connectors:

2x NL4 speakon

箱体形状Enclosure shape:

不规则多边形

箱体材料Enclosure material:

13-ply 18mm birch   wood

油漆Finish:

防水油性漆t

铁网Grille:

多孔铁网+防水棉

吊挂系统Rigging system:

14x 10mm point

尺寸Dimensions(WxDxH):

350*350*520mm

重量Net weight:

14 kg
